DIAMOND WHEELS FOR CNC MACHINES

We offer peripheral wheels for producing pencil edge, trapezoidal as well as other shapes. We supply double-edged grinding wheels and hand-edging wheels, which can be customized.

Inquire

INQUIRE FORM

Product Description
DIAMOND WHEELS FOR CNC MACHINES
TYPE DIA
(mm)
Rim TxB
(mm)
Type Bore (hole) Grit (range) Application
Diamond Segmented peripheral wheels 100 Segmented 8 x (8 to 21) Diamond  22 80 CNC rough grinding - position 1 (Glass 4mm to 19mm)
120 Segmented 8 x (8 to 21) Diamond  22 80 CNC rough grinding - position 1 (Glass 4mm to 19mm)
150 Segmented 8 x (8 to 21) Diamond  22 80 CNC rough grinding - position 1 (Glass 4mm to 19mm)
Diamond Trapazoidal peripheral wheels 100 Continuous 4mm to 19mm Glass Diamond  22 230 - 270 CNC fine profile grinding - position 2 (Glass 4mm to 19mm)
120 Continuous 4mm to 19mm Glass Diamond  22 230 - 270 CNC fine profile grinding - position 2 (Glass 4mm to 19mm)
150 Continuous 4mm to 19mm Glass Diamond  22 230 - 270 CNC fine profile grinding - position 2 (Glass 4mm to 19mm)
Note: Peripheral wheels are available in customisable shapes in the segmented position 1 series and also in a pencil edge profile for the position 2 series. Multi Laminated extra thick wheels are available on request.
