DIAMOND WHEELS

Diamond metal bonded, cup wheels for edging, mitering and beveling. We offer continuous rim, metal bonded wheels for monolithic glass as well as segmented rim, metal bonded wheels for laminated glass.

Our bonding system has been developed to ensure excellent performance, long life and chip-free edges at high grinding speeds.

Inquire

INQUIRE FORM

Product Description
DIA
(mm)
Rim TxB
(mm)
Type Bore (hole) Grit (range) Application
150 Continuous 8 x 5 Diamond  12, 22, 50, 70 100 – 270 Straight line edging
machine  – Flat edge position 1 /
2
150 Segmented 8 x 5 Diamond  12, 22, 50, 70 100 – 270 Straight line edging
machine  – Flat edge position 1 /
2
150 Continuous 10 x 6 Diamond  12, 22, 50, 70 100 – 270 Straight line edging
machine  – Flat edge position 1 /
2
150 Segmented 10 x 6 Diamond  12, 22, 50, 70 100 – 270 Straight line edging
machine  – Flat edge position 1 /
2
150 Segmented 15 x 10 Diamond  12,22 120 Straight line edging
machine  – Flat edge position 1
for multi laminated glass
150 Segmented 15 x 10 Diamond  12,22 230 Straight line edging
machine  – Flat edge position 2
for multi laminated glass
100 / 130 /
150
Continuous 8 x 6 Diamond  12, 22 325 Straight line arris
grinding
150 Continuous 8 x 6 Diamond  12, 22 80 – 170 Bevelling grinding
position 1 / 2
175 Continuous 8 x 8 Diamond  50, 70 100 – 120 Double edge grinding
machine position 1
175 Segmented 8 x 8 Diamond  50, 70 100 – 120 Double edge grinding
machine position 1
Note: Customised wheels are available on request. Segmented wheels are best suited for laminated glass.
DIAMOND WHEELS – Upright edge grinding / Peripheral DEG grinding
DIA
(mm)
Rim TxB

(mm)

Type Bore
(hole)
Grit
(range)
Application
240 Continuous 4mm Glass C profile Diamond  191 230 Upright  peripheral profile grinding wheel.
175 Continuous 4mm to 10mm C Profile Diamond  25 – 70 170 – 270 Upright peripheral
profile grinding wheel.
150 Continuous 4mm to 10mm C Profile Diamond  25 – 70 170 – 270 Upright peripheral
profile grinding wheel.
200 Continuous 4mm to 10mm C Profile Diamond  25 – 70 170 – 270 Upright peripheral
profile grinding wheel.
Note: Customised DEG (Double Edge Grinding) and upright peripheral wheels are available.
